Features a large “L” post plate designed for bolting horizontally through the side of the bearer.

It is an ideal beam support to suit Laminated Veneer Lumber (LVL) construction. This can also be used for butt joining bearers.

“L” Plate: 125mm H x 80mm L x 140mm W, 6mm thick with 8mm and 14mm Bolt Holes

Threaded Rod Specifications:

Length: 200 mm

Rod metric size: M30

Thread Pitch: 3.5mm

Finish: Blue Zinc

*Will suit any of our M30 Adjustable Stump Plate range

$17.29 ex GST
$19.02 inc GST
Quantity
SKU: PPLL/TR30. Categories: , , .

VisaMastercardAmerican ExpressJCB

Categories: , , .

L Post Plate Large w/TR30 Welded

Features a large “L” post plate designed for bolting horizontally through the side of the bearer.

It is an ideal beam support to suit Laminated Veneer Lumber (LVL) construction. This can also be used for butt joining bearers.

“L” Plate: 125mm H x 80mm L x 140mm W, 6mm thick with 8mm and 14mm Bolt Holes

Threaded Rod Specifications:

Length: 200 mm

Rod metric size: M30

Thread Pitch: 3.5mm

Finish: Blue Zinc

*Will suit any of our M30 Adjustable Stump Plate range
